FEATURE

· Increased ground clearance

· Enhanced off-road capabilities

· Larger tire fitment

· Chain -driven and gear-driven bolt on portals optional

· Variety of ratio can be selected accroding to the different needs.

· Gear-driven   -   1:1.2 / 1:1.33

· Chain-driven   -   1:1.16 / 1.1.25 / 1:1.27 / 1:1.36

GEAR-DRIVEN SPECIFICATION

· Recommended wheel offset: ET+50

· Including Bolt-on Portal, Brake Discs, Brake Calliper, Rear Shaft Axle, Brake Hose, Reinforcement Brackets...

· 4.5inch lift

· Suggested tire size:35 - 40inch

· Bolt on ratio：1:1.2 & 1:1.33

· 1:1.2 & 1:1.33 ratio: 17 inch wheel

· Both sides will protrude 15-20cm on each side after installation.

· The specific value depends on the model.

CHAIN-DRIVEN SPECIFICATION

· Recommended wheel offset: ET+50

· Including Bolt-on Portal, Brake Discs, Brake Calliper,  Rear Shaft Axle, Brake Hose, Reinforcement Brackets...

· 4.5inch lift

· Suggested tire size:35 - 40inch

· Bolt on ratio：1:1.16/1:1.25/1:1.27/1:1.36 are available

· 1:1.16 / 1:1.25 / 1:1.27 / 1:1.36 ratio: 17 inch wheel

· Both sides will protrude 15-20cm on each side after installation.

· The specific value depends on the model.

The intesration of TRE4x4 bolt-on portals with Central Tire Infiation Systems (CTIS) enhances vehicle mobillty and performance in challenging terrains.This system allows for dynamic adjustments to tire pressure,maximizingadaptability to varying conditions.

· Aluminum alloy integrated housing

· Two transmission options: gears and chains

· 4.5-inch lift for enhanced height upgraded stance

· Preserves original specs with minimal modifications.

Bolt on portals case/cover :7 series forged aluminum.

Gear :20CrMoTi Steel

Shaft head :40Cr steel

Half shaft :40Cr steel

Chain :50Cr-V Stee
